Product Overview
The Quik-Set Stabilization Plate offers an easy solution to stabilizing earth anchors used to support a mobile home.
Key Features:
- The associated anchor used with this plate must be a soil auger anchor and must be approved by the authority having jurisdiction and installed in accordance with the approved installation instructions in the soil type or range of soil types approved for the anchor.
- Minimum allowable tie angle of 40 degrees from vertical
- Maximum tie design load of 3150 pounds
- Minimum required soil test probe torque value of 200 inch pounds at the level of the plate
- Quick-N-Easy installation, let the drive machine do the work
- Requires little or no hammering
- Inclined steady rest engineered to allow ground anchor to be installed at a slight back angle (10-15 degrees)
